The RPEG x Brook Arcade Encoder is a compact 4-player arcade control board designed for arcade cabinets, fight sticks, LED buttons, LaunchBox setups, MAME builds, and RetroBeast-style systems.

It supports stable 4-player XInput mode, keyboard mode, ARGB LED button control, drag-and-drop profile loading, attract mode lighting, and simple GUI software with no programming required.

Main Features
Supports 4-player XInput mode or Keyboard mode
Permanent stable 4-player order in XInput mode
Supports 13 inputs per player
11 XInput inputs
2 Keyboard inputs
Includes 2 additional always-keyboard inputs per player
8 total admin-style keyboard inputs
Supports 4-player ARGB LED buttons
Designed for Qanba LED buttons
Simple drag-and-drop profile loading
LaunchBox support
Easy-to-use GUI software
Built-in attract mode lighting
No programming skills needed
5V outputs for single LED buttons
USB-C powers both the encoder and LEDs
1ms input delay
Compact size: only 4.5” x 3.5”

Power and USB Notes
USB-C powers both the encoder and the LEDs.
There is also an additional backup USB-C power port for low-powered USB ports.
To use backup power:
Move the black jumper to the bottom position to use the backup power port
Move the black jumper to the top position to use the main data port as power
If using more than 20 buttons, it is recommended to use the secondary USB-C port for LED power with a standard 5V 2A cellphone power adapter.
USB-C cable is not included.
Any good-quality standard USB-A to USB-C cable will work.
For best stability, plugging directly into the motherboard is recommended.

Harness and Wiring Support
Supports 20-pin Brook harnesses
One harness needed per player
Harnesses sold separately
Tool-free push connectors
Push connectors can be double mapped
Example: 2 separate buttons can perform the same action
2 VCC pins are available for Extra Keyboard Button 1 and 2
Wiring guide is shown in the listing pictures

Optional items sold separately:
Mounting plate
Qanba Sapphire USB-C cables
20-pin Brook harnesses

Direction Mode and Hotkey Switching
The board supports Digital 4-Way mode for classic arcade games like Pac-Man.
Hotkey switching is available for:
XInput mode
Keyboard mode
4-Way mode
Left Analog mode
Right Analog mode
D-Pad mode

Hotkey Commands
Hold each combo for about 5 seconds:
Back + Start + Punch 1
Switch to 4-player XInput mode
Back + Start + Kick 1
Switch to Keyboard mode
Back + Start + Punch 1 + Kick 2
Switch to 2-player XInput mode
Player 3 and Player 4 default to keyboard mode
Back + Start + Left
Switch to Left Stick mode
Back + Start + Right
Switch to Right Stick mode
Back + Start + Up
Switch to D-Pad mode

LED and Profile Features
Automatic per-game MAME color profile creator
Load profiles quickly per game
Change LED colors or settings easily
Built-in animations for attract mode
No programming needed
LED daisy chain support
Only 3 wires go to the board per player instead of 4 wires per button

Wiring order is recommended to follow the included diagram so the color profile app works correctly.

Recommended button order:
Top row:
1st Punch
2nd Punch
3rd Punch
4th Punch
Bottom row:
1st Kick
2nd Kick
3rd Kick
4th Kick

If using a 6-button layout or Scantron-style layout, unused LED headers can be skipped using the included skip adapters.
XInput Wiring Assignment

The XInput layout is fixed on purpose so it follows the fight stick tournament standard used by many modern fighting games, including games like Street Fighter.

Most Steam and Windows games work very well with this standard layout.
XInput Button Layout
1P = X
2P = Y
3P = RB
4P = LB
1K = A
2K = B
3K = RT
4K = LT
It is not recommended to change from this layout because the color profile generator will not match if the button order is changed.
For special panels, such as a 2-button layout or Mortal Kombat layout, you can physically wire the buttons in the order you need.

Keyboard mode inputs can be adjusted as you wish.
XInput mode is not adjustable by design.

Benefits Compared to Other Encoders
Perfect player order in XInput mode
XInput and keyboard keys can work at the same time
Ideal for arcade cabinet builds
Controls up to 52 buttons plus LEDs from one board
Uses only one USB-C cable for most setups
Saves space and wiring cost
Easy upgrade for existing cabinets
Works with bare wire or harness options
No extra plugins required
No background software required
No complicated mapping or programming
Simple GUI profile creation instead of editing text files
Keyboard mode prevents game controllers from being detected by the PC
Ideal for light guns, wheels, flight sticks, wireless controllers, or third-party controllers that need to become Player 1

Important Windows XInput Note
Windows officially supports a maximum of 4 XInput devices.
Using a Bluetooth Xbox controller at the same time may cause conflicts because of Windows driver limitations.
If you want to use wireless controllers, change the board to Keyboard mode by holding:
Back + Start + Kick 1 for 5 seconds
When the wireless controller is disconnected, you can return to XInput mode by holding:
Back + Start + Punch 1 for 5 seconds

To use the recovery tool, hold Back + Start while plugging in the USB cable.
Happy Retro Gaming!
Kris
